Longer Lifetime & Deep Cycle: Lithium iron phosphate battery compared with the 200-500 cycles of lead-acid, The service life ratio is long, the weight is light and the number of cycles is up to 6000 times, our lifepo4 battery for home energy storage photovoltaic system used A+ cells, the battery delivers 1280Wh and can endure up to 6000 cycles.(6000 cycles @80% DOD).
Built-in BMS Protection: Our 100Ah lifepo4 battery is built in Reliable BMS Protection. This intelligent design ensures optimal safety and better heat dissipation function to protect battery cells which can prevent the LifePO4 battery from the most common issues causing of battery failures, such as overcharge, over-discharge, over-current, short circuit and high temperature. It also has obtained SDS/UN38.3/CE certifications, ensuring its quality and safety.
Connect for Larger Capacity: 12V LiFePO4 battery 100Ah could connect in parallel & in series for larger capacity. Allow being extended up to 4S or 16P.
Widely Use: Powerful energy expansion system could be widely used for home storage system (avoiding the effects of power outages), off-grid system, RV, Trolling Motor, Boat, Marine, trailer, and outdoor activities.
Product Technical Specification Parameters
|
|
Items
|
Parameters
|
Noted
|
|
Performance
|
Battery Voltage
|
12.8V
|
4S
|
|
Battery Capacity
|
100Ah
|
0.5C
|
|
Charging Cut-Off Voltage
|
14.6V
|
Single Cell 3.65V
|
|
Discharging Cut-Off Voltage
|
10V
|
Single Cell 2.5V-Adjustable
|
|
Charging Current
|
100A
|
Maximum Current-200A
|
|
Discharging Current
|
100A
|
Continuous Working Current
|
|
Internal Resistance
|
≤25mΩ
|
|
|
Protections
|
Over -Charging Voltage Protection
|
14.6V
|
Settable
|
|
Over-Discharging Voltage Protection
|
10V
|
Settable
|
|
Charging Over-Current Protection
|
100A
|
Settable
|
|
Short Circuit Protection
|
YES
|
Remove load or charging can be lifted
|
|
BMS Temperature Protection
|
-25℃~70℃
|
Electricity and ambient temperature protection
|
|
Use Environment
|
Working Temperature
|
-10℃~60℃
|
|
|
Storage And Shipping Temperature
|
-20℃~55℃
|
|
|
Relative Humidity
|
95%
|
|
|
Atmospheric Pressure
|
70kPa-106kPa
|
|
|
Dimensions
|
Weight
|
10Kg
|
Net weight
|
|
Weight
|
11±0.3% Kg
|
Gross Weight
|
|
Size
|
522x238x222±3mm
|
Product Size
|
|
Size
|
595x312x297±3mm
|
Out packing size
|
